All Multi I/O interfaces (connector no. 4) are software-configurable, see "Assigning I/O
Pins" on page39.
1.4.2 Output Timing Interfaces
Table 1-4:
VersaSync outputs (default setup)
OUTPUTSIGNAL
Total
available
DCLS
RS- 232 RS-485 ETH
Connector No.
(see Fig. above)
TTL 10V
10 MHz (1+3) SMA
2,
3
1PPS (2) 1 1 4
ASCII/HaveQuick (1) 1 4
ASCII/NMEA (1) 1 4
NTP server,
PTP v2 master
(1) 1 5
All Multi I/O interfaces (connector no. 4) are software-configurable, see "Assigning I/O
Pins" on page39.
For additional information on configuring pinouts, see "Connectors and their Pinouts" on
the facing page and "Configure I/O Input and Output Settings" on page44.
1.4.3 Other Interfaces
USB serial equivalent: CLI interface (Connector 4)
8
CHAPTER 1 • VersaSync User Manual Rev. 7.0
1.4 Interfaces Overview

Orolia VersaSync Specifications

General

Brand	Orolia
Model	VersaSync
Category	Server
Language	English
