Exterior Covers
M065/M066 4-10 SM
4.3.7 INNER LEFT FRONT COVER
1. Left cover ( p.4-3)
2. Inner left upper cover (
p.4-9)
3. Inner left lower cover (
p.4-11)
4. Turn the lock lever [A] counterclockwise, and then open the drum securing plate [B].
5. Inner left front cover [A] (
x 2)
