System Service Mode
SM Appendix 8-1 M065/M066
Appendix:
SP Mode
Tables
8. APPENDIX: SP MODE TABLES
8.1 SYSTEM SERVICE MODE
8.1.1 SERVICE MODE TABLE
SP1-XXX (Feed)
1001
[Leading Edge Registration] Leading Edge Registration Adjustment
(Tray Location, Paper Type, Color Mode), Paper Type -> Plain, Thick 1, Thick
2 or Thick3
Adjusts the leading edge registration by changing the registration motor
operation timing for each mode.
Increasing a value: an image is moved to the trailing edge of paper.
Decreasing a value: an image is moved to the leading edge of paper.
001 Tray:Plain *ENG
[–9 to 9 / 3.8 / 0.1 mm/step]
002 Tray:M-Thick *ENG
[–9 to 9 / -0.6 / 0.1 mm/step]
003 Tray:Thick1 *ENG
[–9 to 9 / -1.8 / 0.1 mm/step]
004 Tray:Thick2 *ENG
[–9 to 9 / -2.7 / 0.1 mm/step]
005 Tray:Thick3 *ENG
[–9 to 9 / -2.4 / 0.1 mm/step]
006 Tray:Plain:1200dpi *ENG
[–9 to 9 / 1 / 0.1 mm/step]
007 Tray:M-Thick:1200dpi *ENG
[–9 to 9 / -0.7 / 0.1 mm/step]
008 Tray:Thick1:1200dpi *ENG
[–9 to 9 / -0.1 / 0.1 mm/step]
009 By-pass:Plain *ENG
[–9 to 9 / 3.8 / 0.1 mm/step]
010 By-pass: M-Thick *ENG
[–9 to 9 / 0.4 / 0.1 mm/step]
011 By-pass: Thick1 *ENG
[–9 to 9 / -1.3 / 0.1 mm/step]
012 By-pass: Thick2 *ENG
[–9 to 9 / -2.1 / 0.1 mm/step]
013 By-pass: Thick3 *ENG
[–9 to 9 / -1.9 / 0.1 mm/step]
