Fusing
SM 4-87 M065/M066
Replacement
and
Adjustment
4.9.8 HEATING ROLLER THERMOSTAT
1. Fusing front cover ( p.4-74 "Cleaning Unit")
2. Fusing upper cover (
p.4-75 "Pressure Roller Fusing Lamp")
3. Remove the four screws.
4. Remove the plate [A], and then remove the heating roller thermostats [B].
 Do not re-use a thermostat that is already opened. Safety is not guaranteed if
you do this.
To Next Page
