Electrical Components
SM 4-139 M065/M066
Replacement
and
Adjustment
4.13.4 CONTROLLER BOARD
1. Pull out the controller unit ( p.4-136 "HDD")
2. HDD assembly (
p.4-136 "HDD")
3. Disconnect the connector.
4. Controller board [A] (
x 6)
