M065/M066 5-6 SM Appendix
5.1.8 MISSING PARTS OF IMAGES
Symptom Possible cause Necessary actions
Some parts of images are
missing.
Defective PCDU Replace the PCDU.
Defective image transfer
belt unit
Replace the image transfer
belt unit.
Defective paper transfer
roller
Replace the paper transfer
roller.
Defective fusing unit Replace the fusing unit.
5.1.9 DIRTY BACKGROUND
Symptom Possible cause Necessary actions
Backgrounds of one CMYK
color are too dense.
Defective PCDU Replace the PCDU.
Backgrounds of more than
one CMYK are too
dense.color
Defective HVPS Replace the HVPS.
5.1.10 PARTIAL CMY COLOR DOTS
Symptom Possible cause Necessary actions
Unexpected dots of the
same color appear at
irregular intervals.
Defective PCDU Replace the PCDU.
Defective image transfer
belt unit
Replace the image transfer
belt unit.
Defective fusing unit Replace the fusing unit.
