Paper Feed
SM 4-97 M065/M066
Replacement
and
Adjustment
4.10.5 VERTICAL TRANSPORT SENSOR
1. Paper feed unit ( p.4-94)
2. Vertical transport sensor bracket [A] ( x1, x1)
3. Vertical transport sensor [A] (hooks)
