Electrical Components
M065/M066 4-134 SM
4.13 ELECTRICAL COMPONENTS
4.13.1 BOARDS
Rear Cover Open
[A] Bridge Board
[B] Controller Board
[C] HDD
[D] PSU
Controller Box Removal
