Paper Transfer
SM 4-53 M065/M066
Replacement
and
Adjustment
4.7.3 PTR CONTACT SENSOR
1. Right cover ( p.4-4)
2. Top cover (
p.4-6)
3. Inner right front cover (
p.4-12)
4. Motors with bracket (
p.4-68)
5. Sensor bracket [A] ( x 1)
6. PTR contact sensor [A] (
x 1, hooks)
