Exterior Covers
M065/M066 4-12 SM
4.3.10 INNER RIGHT FRONT COVER
1. Right cover ( p.4-4)
2. Top cover (
p.4-6)
3. Connector cover [A] (hook)
4. Disconnect the six harnesses [A] (
x 1).
5. Release the inner right front cover [A] (
x 2).
