Drive Unit
M065/M066 4-66 SM
4.8.6 DEVELOPMENT CLUTCH: K
1. Right cover ( p.4-4)
2. ITB unit/ Drum-K/ Development-K motor (
p.4-65)
3. Development clutch: K cover [A] (
x 2, x 1)
4. Development clutch: K [B]
4.8.7 FUSING/PAPER EXIT MOTOR
1. Right cover ( p.4-4)
2. Top cover (
p.4-6)
3. Inner right front cover (
p.4-12)
4. Fusing/paper exit motor [A] (
x 3, x 1)
