Duplex Unit
M065/M066 4-128 SM
4.12.7 BY-PASS PAPER END SENSOR
1. Duplex unit ( p.4-116)
2. Duplex/By-pass motor bracket with the frame (
p.4-124 "Duplex/By-pass Motor")
3. Sensor holder [A] (
x 1)
4. By-pass paper end sensor [A] ( x 1, hooks)
