Programming and Operating Manual (Milling)
200 6FC5398-4DP10-0BA6, 09/2017
If you desire to edit and store the contour as a section of a main prog
ram, press this softkey.
For more information about programming in the contour editor, see Section "
Free contour
Press this softkey to return to the screen form
for CYCLE72. Parameterize the cycle tech-
Confirm your settings with this softkey. The cycle is then automatically transferred to the
program editor.
The cycle program created as a section of the main program must be stored after the M30
command.
If you desire to recompile the cycle, press this softkey.
Milling a rectangular spigot - CYCLE76
Programming
CYCLE76 (RTP, RFP, SDIS, DP, DPR, LENG, WID, CRAD, PA, PO, STA, MID, FAL, FALD, FFP1, FFD, CDIR, VARI, AP1,
AP2)
Retraction plane (absolute)
RFP REAL Reference plane (absolute)
SDIS REAL Safety clearance (enter without sign)
DP REAL Final drilling depth (absolute)
Final drilling depth relative to the reference plane (enter without sign)
LENG REAL Spigot length
WID REAL Spigot width
Spigot corner radius (enter without sign)
PA REAL Reference point, first axis of plane
Reference point, second axis of plane
Angle between longitudinal axis and first axis of plane
Maximum depth infeed (incremental; enter without sign)
FAL REAL Final machining allowance at the margin contour (incremental)
FALD REAL Finishing allowance at the base (incremental, enter without sign)
Feedrate for surface machining
Feedrate for depth infeed
Milling direction (enter without sign)
Values:
0: Down-cut milling
1: Conventional milling
2: With G2 (independent of spindle direction)
To Next Page
