Programming and Operating Manual (Milling)
216 6FC5398-4DP10-0BA6, 09/2017
Circumferential slot - SLOT2
Programming
SLOT2 (RTP, RFP, SDIS, DP, DPR, NUM, AFSL, WID, CPA, CPO, RAD, STA1, INDA, FFD, FFP1, MID, CDIR, FAL, VARI,
MIDF, FFP2, SSF, FFCP)
Retraction plane (absolute)
Reference plane (absolute)
Safety clearance (enter without sign)
DP REAL Slot depth (absolute)
DPR REAL Slot depth relative to the reference plane (enter without sign)
AFSL REAL Angle for the slot length (enter without sign)
Circumferential slot width (enter without sign)
Center point of circle (absolute), first axis of the plane
CPO REAL Center point of circle (absolute), second axis of the plane
RAD REAL Radius of the circle (enter without sign)
STA1 REAL Starting angle
FFD REAL Feedrate for depth infeed
FFP1 REAL Feedrate for surface machining
Maximum infeed depth for one infeed (enter without sign)
CDIR INT Milling direction for machining the circumferential slot
Values: 2 (for G2), 3 (for G3)
FAL REAL Finishing allowance at the slot edge (enter without sign)
VARI INT Machining type
Values: 0 = complete machining, 1 = roughing, 2 = finishing
MIDF REAL Maximum infeed depth for finishing
FFCP REAL Feedrate for intermediate positioning on a circular path, in mm/min
Note
The cycle requires a milling cutter with an "end tooth cutting across center" (DIN844).
