Siemens SINUMERIK 808D User Manual

Programming and Operating Manual (Milling)
76 6FC5398-4DP10-0BA6, 09/2017
Note
Do not remove the USB stick in the process of data backup if you choose USB as the target directory.
Pressing <CTRL + S> when you are in any operating area creates a startup archive on the connected USB stick. In addition,
it automatically saves the action log to the USB stick.
Restoring a startup archive
+
1.
Selec
t the system data operating area.
2.
Press this soft
key to open the startup archive window.
3.
Select th
e following option and press this softkey to restore the startup archive:
4.
Select the backup path to lo
cate the archive file and press this softkey to confirm.
5.
Press this softkey to confirm the archive information.
6.
Press this softkey to continue and start restoring the startup archive. The control system
restarts to complete restoring the archive.
10.12.2.2
External data backup of separate files
In the program management operating area, program files or directories can be copied into another directory or onto a
different drive by means of copying and pasting operations.
Operating sequence
1.
Select the program management operating area.
2.
Enter the program directory.
3.
Select the program file or directory to be backed up.
4.
Press this softkey to copy the file to the clipboard.
5.
Select a desired directo
ry or drive as the data target.
Backs up the files in the folder for storing the user cycles on the control system. This folder
is visible with the manufacturer password.
Backs up the files onto a USB stick.
Backs up the files onto a computer. This requires a connected network drive on the control
system. For more information, see section "
Configuring the network drive (Page 67)".
