Siemens SINUMERIK 808D User Manual

Programming and Operating Manual (Milling)
328 6FC5398-4DP10-0BA6, 09/2017
Address
Significance
Value assignments
Information
Programming
G3 Circular interpolation in counter-clockwise
direction (in conjunction with a third axis
and TURN=... also helix interpolation ->
see under TURN)
G3 ... ; otherwise as for G2
CIP
Circular interpolation through intermediate
point
CIP X... Y... Z... I1=... J1=...
K1=... F...
CT Circular interpolation; tangential transition N10 ...
N20 CT X... Y... F... ;circle,
tangential transition to the
previous path segment
G33
Thread cutting, tapping with constant pitch
S... M... ;Spindle speed, direc-
tion G33 Z... K...; Thread drill-
ing
with
compensating chuck,
e.g. in Z axis
G331 Thread interpolation N10 SPOS=... ; Spindle in
position control
N20 G331 Z... K... S... ; tap-
ping
without
compensating
chuck e.g. in Z axis; RH or LH
thread is defined via the sign
of the pitch (e.g. K+):
+ : as with M3
- : as with M4
G332 Thread interpolation - retraction G332 Z... K... ;
Rigid tapping
,
e.g. in Z axis,
retraction mo-
tion
; sign of pitch as for G331
G4 Dwell time 2: Special motions, non-modal G4 F...;separate block, F:
Time in seconds
or
G4 S.... ;separate block, S: in
spindle revolutions
G63 Tapping with compensating chuck G63 Z... F... S... M...
G74
Reference point approach
G74 X=0 Y=0 Z=0; separate
block, (machine axis identifi-
er!)
G75
Fixed point approach
G75 X=0 Y=0 Z=0; separate
block, (machine axis identifi-
er!)
G147 SAR - Approach with a straight line G147 G41 DISR=... DISCL=...
FAD=... F... X... Y... Z...
G148 SAR - Retract with a straight line G148 G40 DISR=... DISCL=...
FAD=... F... X... Y... Z...
G247 SAR - Approach with a quadrant G247 G41 DISR=... DISCL=...
FAD=... F... X... Y... Z...
G248 SAR - Retract with a quadrant G248 G40 DISR=... DISCL=...
FAD=... F... X... Y... Z...
G347 SAR - Approach with a semicircle G347 G41 DISR=... DISCL=...
FAD=... F... X... Y... Z...
G348 SAR - Retract with a semicircle G348 G40 DISR=... DISCL=...
FAD=... F... X... Y... Z...
TRANS
Translation, programmable
3: Write memory, non-modal
TRANS X... Y... Z...; separate
block
