11.2.2 Controlling the Basic Functions via PROFIsafe
The following table lists the response times
1)
from receiving the PROFIsafe Telegram in the
drive up to initiating the particular response.
Table 11-2 Response times when controlling via PROFIsafe
Function Worst case for
Drive system has no fault A fault is present
STO 5 · r9780 + t_E
2)
5 · r9780 + t_E
2)
SBC 6 · r9780 + t_E
2)
10 · r9780 + t_E
2)
SS1/SS1E (time-controlled)
Selection until STO is initiated 5 · r9780 + p9652 + t_K
2)
5 · r9780 + p9652 + t_K
2)
SS1/SS1E (time-controlled)
Selection until SBC is initiated 6 · r9780 + p9652 + t_K
2)
10 · r9780 + p9652 + t_K
2)
SS1 (time-controlled)
Selection until braking is initiated 5 · r9780 + 2 ms + t_K
2)
5 · r9780 + 2 ms + t_K
2)
1)
The specified response times involve internal SINAMICS response times. Program run times in the F‑host and the
propagation time via PROFINET are not taken into account. When calculating the response times between the F-CPU and
the converter, you must take into account that faults in the communication can result in a safety function only being selected
after the PROFIsafe monitoring time (F_WD_Time) has expired. The PROFIsafe monitoring time (F_WD_Time) must also
be included in the calculation when an error occurs.
2)
t_K is the time for internal communication within the SINAMICS module; t_K can be determined as follows:
t_K = To (for To, see parameter r2064[4])
11.2.3 Control of the Extended/Advanced Functions via PROFIsafe
The following table lists the response times
1) 2)
from receiving the PROFIsafe Telegram in the
drive up to initiating the particular response.
Table 11-3 Response times when controlling via PROFIsafe
Function Worst case for
Drive system has no fault A fault is present
STO 5 · p9500
8)
+ r9780 + t_K
6)
5 · p9500
8)
+ 2 · r9780 + t_K
6)
SBC 5 · p9500
8)
+ 2 · r9780 + t_K
6)
5 · p9500
8)
+ 6 · r9780 + t_K
6)
SS1 (time controlled), SS1E, SS2E: Time from select‐
ing up to starting the safe timer
SS1 (acceleration controlled), SS2: Time from select‐
ing up to initiating braking
SOS: Time from selecting up to starting standstill mon‐
itoring
5 · p9500
8)
+ 2 ms + t_K
6)
5 · p9500
8)
+ 2 ms + t_K
6)
SBR or SAM (limit value violation until STO active) 2 · p9500 + r9780 2.5 · p9500 + r9780 + t_ACT
5)
SOS standstill tolerance window violated 1.5 · p9500 + 2 ms 3 · p9500 + 2 ms + t_ACT
5)
SLS speed limit violated
3)
2 · p9500 + 2 ms 3.5 · p9500 + 2 ms + t_ACT
5)
SSM
4)
4 · p9500 4.5 · p9500 + t_ACT
5)
SDI (limit value violation until braking is initiated) 1.5 · p9500 + 2 ms 3 · p9500 + 2 ms + t_ACT
5)
System features
11.2 Response times
Safety Integrated (with SINAMICS S120)
384 Commissioning Manual, 02/2020, A5E46305916B AB
