2.9.2 Licensing axes/spindles and F-PLC
To use Safety Integrated, you require in addition to the license for SIMATIC STEP 7 Safety
Advanced (TIA Portal), the appropriate software options for the RT function:
Table 2-8 Software options when using Safety Integrated
Software option Article No. Explanation
SINUMERIK XX
Safety Integrated
/SI logic
6FC5800-0AS60-0YB0 Activate the F-PLC in the SINUMERIK control sys‐
tem to be able to process the failsafe sensors and
actuators in an F-program.
SINAMICS S120
Safety Integrated per
axis of an external drive
6SL3074-0AA10-0AA0 Each axis that is to be operated with Safety Inte‐
grated Extended and Advanced Functions re‐
quires a license. On the other hand, Basic Func‐
tions do not require a license.
The article number at the left shows a Safety Inte‐
grated Extended Function for CompactFlash card
as example.
When required, you can order additional licenses.
For every license that is ordered, you receive a
Certificate of Licenses, which you can then use to
obtain licenses from the license database via the
"WEB License Manager".
Note:
Only for SINAMICS are the Safety Integrated Func‐
tions SP, SLP and SCA classified as Advanced
Functions. They require a different type of license
than the Extended Functions.
Depending on the functions used, you must license the appropriate software options and set in
the machine data:
● MD19500 $MN_SAFE_PLC_LOGIC: Safety Integrated/F-PLC basic option
Additional licensing information:
You can find additional information about licensing in:
Commissioning Manual MCU: NC, PLC, Drive (https://
support.industry.siemens.com/cs/de/en/view/109769920)
Fundamentals
2.9 Safety components and licensing
Safety Integrated (with SINAMICS S120)
52 Commissioning Manual, 02/2020, A5E46305916B AB
