Functions
6-84 7SA6 Manual
C53000-G1176-C156-2
6.4.3 Settings
Protection Data
Interfaces
Addresses which have an „A“ attached to its end can only be changed with DIGSI
®
4
in “
Additional Settings“.
Topological Data
6.4.4 Information Overview
Protection Data
Interfaces
Addr. Setting Title Setting Options Default Setting Comments
4509 T-DATA DISTURB 0.05..2.00 sec 0.10 sec Time delay for data disturbance
alarm
4510 T-DATAFAIL 0.0..60.0 sec 6.0 sec Time del for transmission failure
alarm
4511 Td ResetRemote 0.00..300.00 sec; ∞ 0.00 sec Remote signal RESET DELAY
for comm.fail
4501 STATE PROT I 1 ON
OFF
ON Stateofprotectioninterface1
4502 CONNEC. 1 OVER Direct connection with fibre
optic cabel
Communication converter
with 64 kBit/s
Communication converter
with 128 kBit/s
Communication converter
with 512 kBit/s
Direct connection
with fibre optic
cabel
Connection 1 over
4505A PROT 1 T-DELAY 0.1..30.0 ms 30.0 ms Prot 1: Maximal permissible
delay time
Addr. Setting Title Setting Options Default Setting Comments
4701 ID OF RELAY 1 1..65534 1 Identification number of relay 1
4702 ID OF RELAY 2 1..65534 2 Identification number of relay 2
4703 ID OF RELAY 3 1..65534 3 Identification number of relay 3
4710 LOCAL RELAY relay 1
relay 2
relay 3
relay 1 Local relay is
F.No. Alarm Comments
3227 >PI1 light off >Prot Int 1: Transmitter is switched off
3196 local Teststate Local relay in Teststate
3215 Wrong Firmware Incompatible Firmware Versions
