Appendix
A-66 7SA6 Manual
C53000-G1176-C156-2
A.4 Preset Configurations
Presettings The LED indication presettings which are preset in the device when it leaves the
factory are summarised in Table A-1. Please take into consideration that LED8 to
LED14 is not available in 7SA610.
The presettings of the binary inputs are listed (dependent on the ordering variant) in
Tables A-2 to A-4.
The presettings of the binary outputs are listed (dependent on the ordering variant) in
Tables A-5 to A-9. The General Diagrams in Appendix A, A.2 show which binary
outputs can be used as accelerated binary outputs, i. e. suited for a fast command
tripping.
Positions that are not indicated in the following tables have no presetting.
Table A-1 LED indication presettings
LED LCD Text Function No. Remarks
LED1 Relay PICKUP L1 511 Device (general) trip, latched
LED 2 Relay PICKUP L2 503 Device (general) pick up phase L1,
latched
LED3 Relay PICKUP L2 504 Device (general) pick up phase L2,
latched
LED4 Relay PICKUP L3 505 Device (general) pick up phase L3,
latched
LED5 Relay PICKUP E 506 Device (general) pick up earth fault,
latched
LED6 EF reverse
Dis. reverse
1359
3720
Device (general) pick up reverse
fault, latched
LED7 —
2
)—
2
)nopre-setting
2
)
Relay TRIP 1pL1
Relay TRIP 1pL2
Relay TRIP 1pL3
512
1
)
513
1
)
514
1
)
Device (general) trip 1-pole,
latched
1
)
LED8 Dis.TripZ1/1p
DisTRIP3p. Z1sf
DisTRIP3p. Z1mf
3811
1
)
3823
3824
Distance protection trip in zone Z1,
latched
LED9 Dis.TripZ1B1p
DisTRIP3p.Z1Bsf
DisTRIP3p Z1Bmf
3813
1
)
3825
3826
Distance protection trip in zone Z1B,
latched
LED10 Dis.TripZ2/1p
Dis.TripZ2/3p
3816
1
)
3817
Distance protection trip in zone Z2,
latched
LED11 Dis.TripZ3/T3
Dis.TRIP 3p. Z4
Dis.TRIP 3p. Z5
3818
3821
3822
Distance protection trip in zones Z3
to Z5, latched
1
) devices with single- and three-pole tripping
2
) devices with three-pole tripping only
3
) devices with automatic reclosure
