Siemens siprotec 7SA6 User Manual

Appendix
B-23
7SA6 Manual
C53000-G1176-C156-2
B.2 List of Information
NOTE: The following table lists all data which are available in the maximum complement of the device. De-
pendent on the ordered model, only those data may be present which are valid for the individual version.
The symbol ’
> ’ indicates that the source of the indication is a binary input.
Indications for T103 are always reported ON / OFF if they are subject to general interrogation for
IEC 60870-5-103. If not, they are reported only as ON.
New user-defined indications or such newly allocated to IEC 60870-5-103 are set to ON / OFF and subjected
to general interrogation if the information type is not a spontaneous event (".._Ev").
In columns “Event Log”, “Trip Log” and “Ground Fault Log” the following applies:
UPPER CASE:ON/OFF definitely set, not allocatable
lower case:preset, allocatable
*:not preset, allocatable
<blank>:neither preset nor allocata
F.No. Description Function Type of
Informa-
tion
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off Trip (Fault) Log On/Off Ground Fault Log On/Off Marked in Oscill. Record LED Binary Input Function Key Binary Output Chatter Blocking Type Information-No Data Unit (ASDU) General Interrogation
3 >Synchronize Internal Real Time Clock
(>Time Synch)
Device SP * * LED BI BO
4 >Trigger Waveform Capture
(>Trig.Wave.Cap.)
Oscillographic
Fault Records
SP ON * M LED BI BO
5 >Reset LED (>Reset LED) Device SP * * LED BI BO
7 >Setting Group Select Bit 0 (>Set Group
Bit0)
Change Group SP * * LED BI BO
8 >Setting Group Select Bit 1 (>Set Group
Bit1)
Change Group SP * * LED BI BO
15 >Test mode (>Test mode) Device SP ON
OFF
* LED BI BO 135 53 1 GI
16 >Stop data transmission (>DataStop) Device SP * * LED BI BO 135 54 1 GI
51 Device is Operational and Protecting
(Device OK)
Device OUT ON
OFF
* LED BO 135 81 1 GI
52 At Least 1 Protection Funct. is Active (Pro-
tActive)
Device IntSP ON
OFF
* LED BO 128 18 1 GI
55 Reset Device (Reset Device) Device OUT * * LED BO 128 4 1
56 Initial Start of Device (Initial Start) Device OUT ON * LED BO 128 5 1
60 Reset LED (Reset LED) Device OUT_Ev ON * LED BO 128 19 1
67 Resume (Resume) Device OUT ON * LED BO 135 97 1
68 Clock Synchronization Error (Clock Syn-
cError)
Device OUT ON
OFF
* LED BO
69 Daylight Saving Time (DayLightSavTime) Device OUT ON
OFF
* LED BO
70 Setting calculation is running (Settings
Calc.)
Device OUT ON
OFF
* LED BO 128 22 1 GI
