A-17SA6 Manual
C53000-G1176-C156-2
Appendix A
This appendix is primarily a reference for the experienced user. This Chapter provides
ordering information for the models of 7SA6. General diagrams indicating the terminal
connections of the 7SA6 models are included. Connection examples show the proper
connections of the device to primary equipment in typical power system
configurations. Tables with all settings and all information available in a 7SA6
equipped with all options are provided.
A.1 Ordering Information and Accessories A-2
A.2 General Diagrams A-13
A.3 Connection Examples A-51
A.4 Preset Configurations A-66
A.5 Protocol Dependent Functions A-75
