6.9.3 Settings
Addresses which have an „A“ attached to its end can only be changed with DIGSI
®
4
in “
Additional Settings“.
6.9.4 Information Overview
Addr. Setting Title Setting Options Default Setting Comments
2501 FCT Weak Infeed OFF
Echo only
Echo and Trip
Echo only Weak Infeed function is
2502A Trip/Echo DELAY 0.00..30.00 sec 0.04 sec Trip / Echo Delay after carrier
receipt
2503A Trip EXTENSION 0.00..30.00 sec 0.05 sec Trip Extension / Echo Impulse
time
2505 UNDERVOLTAGE 2..70 V 25 V Undervoltage (ph-e)
F.No. Alarm Comments
4203 >BLOCK Weak Inf >BLOCK Weak Infeed Trip function
4221 WeakInf. OFF Weak Infeed Trip fct. is switched OFF
4222 Weak Inf. BLOCK Weak Infeed Trip function is BLOCKED
4223 Weak Inf ACTIVE Weak Infeed Trip function is ACTIVE
4231 WeakInf. PICKUP Weak Infeed Trip function PICKED UP
4232 W/I Pickup L1 Weak Infeed Trip function PICKUP L1
4233 W/I Pickup L2 Weak Infeed Trip function PICKUP L2
4234 W/I Pickup L3 Weak Infeed Trip function PICKUP L3
4241 WeakInfeed TRIP Weak Infeed General TRIP command
4242 Weak TRIP 1p.L1 Weak Infeed TRIP command - Only L1
4243 Weak TRIP 1p.L2 Weak Infeed TRIP command - Only L2
4244 Weak TRIP 1p.L3 Weak Infeed TRIP command - Only L3
4245 Weak TRIP L123 Weak Infeed TRIP command L123
4246 ECHO SIGNAL ECHO Send SIGNAL
