6.11.4 Information Overview
2624 I> Telep/BI NO
YES
NO Instantaneous trip via Teleprot./
BI
2625 I> SOTF NO
YES
NO Instantaneous trip after Swit-
chOnToFault
2640 Ip> 0.10..4.00 A; ∞∞AIp>Pickup
2642 T Ip Time Dial 0.05..3.00 sec; ∞ 0.50 sec T Ip Time Dial
2643 Time Dial TD Ip 0.50..15.00; ∞ 5.00 Time Dial TD Ip
2646 T Ip Add 0.00..30.00 sec 0.00 sec T Ip Additional Time Delay
2650 3I0p PICKUP 0.05..4.00 A; ∞∞A3I0pPickup
2652 T 3I0p TimeDial 0.05..3.00 sec; ∞ 0.50 sec T 3I0p Time Dial
2653 TimeDial TD3I0p 0.50..15.00; ∞ 5.00 Time Dial TD 3I0p
2656 T 3I0p Add 0.00..30.00 sec 0.00 sec T 3I0p Additional Time Delay
2660 IEC Curve Normal Inverse
Very Inverse
Extremely Inverse
Longtimeinverse
Normal Inverse IEC Curve
2661 ANSI Curve Inverse
Short Inverse
Long Inverse
Moderately Inverse
Very Inverse
Extremely Inverse
Definite Inverse
Inverse ANSI Curve
2670 I(3I0)p Tele/BI NO
YES
NO Instantaneous trip via Teleprot./
BI
2671 I(3I0)p SOTF NO
YES
NO Instantaneous trip after Swit-
chOnToFault
2630 Iph> STUB 0.10..25.00 A; ∞ 1.50 A Iph> STUB Pickup
2631 T Iph STUB 0.00..30.00 sec; ∞ 0.30 sec T Iph STUB Time delay
2632 3I0> STUB 0.05..25.00 A; ∞ 0.20 A 3I0> STUB Pickup
2633 T 3I0 STUB 0.00..30.00 sec; ∞ 2.00 sec T 3I0 STUB Time delay
2634 I-STUB Telep/BI NO
YES
NO Instantaneous trip via Teleprot./
BI
2635 I-STUB SOTF NO
YES
NO Instantaneous trip after Swit-
chOnToFault
Addr. Setting Title Setting Options Default Setting Comments
F.No. Alarm Comments
7104 >BLOCK O/C I>> >BLOCK Backup OverCurrent I>>
7105 >BLOCK O/C I> >BLOCK Backup OverCurrent I>
