Technical Data
10-6 7SA6 Manual
C53000-G1176-C156
1
) UL–listed with the following nominal value:
120 V ac Pilot duty, B300
240 V ac Pilot duty, B300
240 V ac 5 A General Purpose
24 V dc 5 A General Purpose
48Vdc 0.8AGeneralPurpose
240 V dc 0.1 A General Purpose
120 V ac 1/6 hp (4.4 FLA)
240 V ac 1/2 hp (4.9 FLA)
2
) UL–listed with the following nominal value:
240 V dc 1.6 FLA
120 V dc 3.2 FLA
60 V dc 5.5 FLA
10.1.4 Communications Interfaces
Protection Data
Interfaces
see Section 10.8
Operating Interface – Connection front panel, non-isolated, RS 232
9-pin DSUB socket
for connection to a personal computer
– Operation with DIGSI
®
4
– Transmission speed min. 4800 Baud; max. 115200 Baud
factory setting: 38400 Baud; parity: 8E1
– Maximum transmission distance 15 m (50 ft)
Rear Service/
Modem Interface
(optional)
RS232/RS485/Optical isolated interface for data transfer
acc. ordered version
Operation with DIGSI
®
4
RS232
– Connection for flush mounted case rear panel, mounting location “C”
9-pin DSUB socket
for surface mounted case at the inclined housing on the case bottom
9-pin DSUB socket
shielded data cable
– Test voltage 500 V; 50 Hz
– Transmission speed min. 4800 Baud; max. 115200 Baud
factory setting: 38400 Baud
– Maximum transmission distance max. 15 m (50 ft)
RS485
– Connection for flush mounted case rear panel, mounting location “C”
9-pin DSUB socket
for surface mounted case at the inclined housing on case bottom
9-pin DSUB socket
