Functions
6-154 7SA6 Manual
C53000-G1176-C156-2
6.8.3 Settings
Addresses which have an „A“ attached to its end can only be changed with DIGSI
®
4
in “
Additional Settings“.
Addr. Setting Title Setting Options Default Setting Comments
3201 FCT Telep. E/F ON
OFF
ON Teleprotection for Earth Fault O/
C
3202 Line Config. Two Terminals
Three Terminals
Two Terminals Line Configuration
3203A Send Prolong. 0.00..30.00 sec 0.05 sec Time for send signal prolonga-
tion
3207A Delay for alarm 0.00..30.00 sec 10.00 sec Unblocking: Time Delay for
Alarm
3208 Release Delay 0.000..30.000 sec 0.000 sec Time Delay for release after pik-
kup
3209A TrBlk Wait Time 0.00..30.00 sec; ∞ 0.04 sec Transient Block.: Duration exter-
nal flt.
3210A TrBlk BlockTime 0.00..30.00 sec 0.05 sec Transient Block.: Blk.T. after ext.
flt.
