Control During Operation
7-58 7SA6 Manual
C53000-G1176-C156-2
From PC with
DIGSI
®
4
When the On-line window in DIGSI
®
4 is opened with a double click, the operating
functions for the device appear in the left part of the window (Figure 7-35). Clicking on
Controls brings up the function selection in the right side of the window (Figure 7-
50). By double clicking on
Breaker/Switches, a dialog field is opened in which,
among other options, the option for interlocked and non-interlocked (Unlock) switching
is offered.
To switch operating resources without a check of the associated interlocking condi-
tions, mark the option
Unlock by clicking in that field, see subsection 7.4.1.
To set the switching mode for interlocked switching, the aforementioned option field
must not be marked. The marking is removed by clicking in the field again.
Further switching operations are possible until the dialog field
Breaker/Switches
is closed, or the switching mode is changed.
7.4.8 Control Messages
In the course of system control, the device generates several messages that docu-
ment the process. For example, messages may be given to report the end of a com-
mand or provide the reason for a command denial. These messages and the associ-
ated causes are listed in Table 7-6, together with other messages for the control of de-
vice functions.
:
Table 7-6 Possible Control Messages
Message Text Message Cause
System Error Interruption by system error
Man.Overwrite OK Return routing carried out
Man.Overwrite Fail Return routing cannot be carried out
Control Abort OK Command interruption carried out correctly
Control Abort Fail Process cannot be interrupted because no command is issued,
command runs in different switching direction, or interruption is not
planned or set up.
Control Executed Command was correctly executed and ended
Control Failed Refusal because the command number or the origination source is
not permitted
Interlocked Refusal because the communication interface was blocked or the
command object is blocked by a protective function.
Switchgr.Intlocked Refusal because the command object is subject to field interlock-
ing
Switch in Position Refusal because the present switch position = command direction
Setting Error Refusal because of a parameter fault, such as unknown command
type
Not Authorized Command from ON-SITE refused because command object is
subject to switching authority, which is set to REMOTE
Control Expired Refusal because command is too old (expiry monitor)
No Control Device Information address is not planned as command output
