Siemens siprotec 7SA6 User Manual

Technical Data
10-477SA6 Manual
C53000-G1176-C156
10.22 Dimensions
Housing for Panel
Flush Mounting or
Cubicle Installation
(Size
1
/
3
x 19”)
Figure 10-7 Dimensions 7SA6 for panel flush mounting or cubicle installation (size
1
/
3
x19”)
2
29.5
34
Mounting plate
Side View (with screwed terminals)
244 (9.61)
266 (10.47)
2
29.5
34
Mounting plate
29 30
Side View (with plug-in terminals)
Dimensions in mm
(1.16)
172 (6.77)
(1.34)
(0.08)
(1.16)
(1.18)(1.14)
172 (6.77)
266 (10.47)
244 (9.61)
(0.08)
(1.34)
Values in brackets in inches
146
+2
(5.75
+ 0.07)
255.8
±
0.3
(10.07
±
0.01
)
245
+1
(9.64
+0.03
)
5(0.19)
6 (0.24)
Panel Cut-Out
150 (5.91)
145 (5.71)
Rear View
or M4
105
± 0.5
(4.13
±0.01
)
131.5
± 0.3
(5.17
±0.01
)
7.3 (0.28)
13.2 (0.51)
5.4 (0.21)
