Technical Data
10-37SA6 Manual
C53000-G1176-C156
Permissible AC ripple voltage,
Peak to peak
≤15 % of nominal power supply
Power consumption
– quiescient approx. 5 W
– energized with 7SA610
∗–∗A/E/J approx. 8 W
with 7SA610
∗–∗B/F/K approx. 7 W
with 7SA6
∗1∗–∗A/E/J/M/N/P approx.14 W
with 7SA6
∗1∗–∗B/F/K approx.12 W
with 7SA6
∗2∗–∗A/E/J/M/P/R approx.15 W
with 7SA613
∗–∗A/M approx. 15 W
with 7SA6
∗2∗–∗B/K/F/N/Q/S approx.20 W
with 7SA6
∗2∗–∗C/G/L approx.16 W
plus approx. 1.5 W per interface module
Bridging time for failure/short-circuit
≥50 ms at U
NDC
=48VandU
NDC
≥ 110 V
of the power supply
≥20 ms at U
NDC
=24VandU
NDC
=60V
Alternating Voltage Voltage supply via integrated AC/DC converter
Power consumption
– quiescient approx. 7 VA
– energized with 7SA610
∗–∗A/E/J approx.14 VA
with 7SA610
∗–∗B/F/K approx.12 VA
with 7SA6
∗1∗–∗A/E/J/M/N/P approx.17 VA
with 7SA6
∗1∗–∗B/F/K approx.17 VA
with 7SA6
∗2∗–∗A/E/J/M/P/R approx. 20 VA
with 7SA613
∗–∗A/M approx. 20 VA
with7SA6
∗2∗–∗B/K/F/N/Q/S approx.23 VA
with 7SA6
∗2∗–∗C/G/L approx.21 VA
plus approx. 1.5 VA per interface module
Bridging time for failure/short-circuit
≥ 50 ms
of the power supply
10.1.3 Binary Inputs and Outputs
Binary Inputs Quantity
-7SA610
∗–∗A/E/J 5 (allocatable)
-7SA610
∗–∗B/F/K 7 (allocatable)
-7SA61/31
∗–∗A/E/J/M/N/P 13(allocatable)
-7SA61/31
∗–∗B/F/K 20(allocatable)
-7SA61/32
∗–∗A/E/J/M/P/R 21(allocatable)
-7SA61/32
∗–∗B/F/K/N/Q/S 29(allocatable)
-7SA61/32
∗–∗C/G/L 33(allocatable)
-7SA613
∗–∗A/M 21(allocatable)
Nominal power supply alternating voltage U
NAC
115 VAC
Permissible voltage ranges 92 to 132 VAC
