TOHATSU MFS 9.9 User Manual

1 Cylinder Head 1
2 Cylinder Head Gasket 1
3 Dowel Pin, 6-12 2
4 Cylinder Head Bolt 6 M8 L=60mm
5 Bolt 2 M6 L=25mm
6 Bolt 1 M6 L=40mm
7 Washer 3
8 Cylinder Head Cover 1
9 Cylinder Head Cover Gasket 1
10 Bolt 4 M6 L=30mm
5-8
Power Unit
4st 9.9/15/20 2008
1
6 N·m (4 lb·ft) [0.6 kgf·m]
2
9 N·m (7 lb·ft) [0.9 kgf·m]
1
10 N·m ( 7 lb·ft) [1.0 kgf·m]
2
30 N·m (22 lb·ft) [3.0 kgf·m]
1
6 N·m (4 lb·ft) [0.6 kgf·m]
2
10 N·m (7 lb·ft) [1.0 kgf·m]
1
6 N·m (4 lb·ft) [0.6 kgf·m]
2
10 N·m (7 lb·ft) [1.0 kgf·m]
SOC
OIL-COMP.
GM
SOCSOC
18 N·m (13 lb·ft) [1.8 kgf·m]
4st OIL
4st
OIL
4st OIL
4st
OIL
2
3
3
13
7
6
4
7
5
8
10
12
11
9
1
Cylinder Head
Do not reuse.
P/L Fig. 1
OIL-COMP.
GM
SOCSOC
SOC
4st
OIL
4st OIL
Ref.
No.
Description
Remarks
Q'ty
11 Engine Oil Filler Cap 1
12 O-Ring, 3.1-24.4 1
13 Spark Plug 2 NGK : DCPR6E
Ref.
No.
Description Remarks
Q'ty
Do not reuse.
Do not reuse.
E_MFS20C_ch05_090105.qxd 09.1.20 5:25 PM ページ 8
