5-64
Power Unit
4st 9.9/15/20 2008
3. Put rope in the groove of reel 1 and gently turn reel 1
clockwise to release tension of starter spring.
4. Remove start shaft bolt 4, and then, friction plate 3 and
spring 2.
5. Take out reel carefully.
TB
13421342
1342
4
2
3
LIT
GREASE
LIT
1 Reel
2 Friction Spring
3 Friction Plate
4 Starter Shaft Bolt
47) Disassembly of Recoil Starter
1. Disconnect upper starter lock cable.
2. Remove bolts, and then, recoil starter and belt cover.
6. Remove bushing 5 and tapping screw 6, and then,
ratchet 7, ratchet guide 8, and return spring 9.
5
7
8
9
0
LIT
GREASE
LIT
LIT
GREASE
LIT
6
5 Bushing
6 Tapping screwl
7 Reel
8 Ratchet
9 Ratchet Guide
0 Return Spring
E_MFS20C_ch05_090105.qxd 09.1.20 5:25 PM ページ 64
