8-6
Electrical System
4st 9.9/15/20 2008
1 Rectifier
2 Choke Solenoid
3 Ignition Coil
4 Starter Motor
5 Oil Pressure Switch
6 Alternator
7 Fuse
8 Pulser Coil
8
4
7
5
3
1
2
6
Top View
< EP Model >
E_MFS20C_ch08_081203.qxd 09.1.20 5:32 PM ページ 6
