5-18
Power Unit
4st 9.9/15/20 2008
5.
Remove spring pin
3
and disconnect shift link rod.
3
3.
Disconnect warning lamp, starter switch and stop switch.
(Tiller Handle Model)
1
2
4.
Disconnect remote controller harness coupler
2
. (Remote
Control Model)
4) Removing Power Unit
1.
Disconnect upper starter lock cable.
2.
Disconnect battery cords
1
(2). (Electric start model)
E_MFS20C_ch05_090105.qxd
09.1.20
5:25
PM
ページ
18
120
