Toro Diesel Z Master User Manual

SPECIFICATIONS
2-1Z580/Z593/Z595 Diesel Service Manual
2
Z593-D Pro Performance Z595-D Pro Performance
23 hp Kubota® 3 Cyl Diesel 52”/60” Turbo Force
25 hp Kubota® 3 Cyl Diesel 52”/60”/72” Turbo Force
Specifi cations Z593-D & Z595-D
Confi gurations
Power System
Z593-D Pro Performance Z595-D Pro Performance
Heavy Duty Canister Air Cleaner Standard Standard
Clutch 200 ft-lbs. (271 Nm) Electromagnetic 200 ft-lbs. (271 Nm) Electromagnetic
Hydraulic Pumps Tandem Hydro-Gear® 16cc, w/shock
valves
Hydro-Gear® 16cc, w/system relief
Wheel Motors(2) Hydro-Gear® 18E, 1-1/4” (3.175cm)
Tapered Shaft
Hydro-Gear® 18E, 1-1/4” (3.175cm)
Tapered Shaft
Maximum Ground Speed (f/r) 11 mph (17.7 km/hr) /
6.3 mph (10 km/hr)
11.2 mph (18 km/hr) /
6.3 mph (10 km/hr)
Hour Meter Standard Standard
Rear Drive Tires 23 x 9.5 - 12 (52”)
24 x 12 - 12 (60”)
23 x 9.5 -12 (52”)
24 x 12 - 12 (60” & 72”)
Front Caster Tires 13 x 6.50 - 6 13 x 6.50 - 6
Flat-free Semi-pneumatic
Fuel / Capacity Diesel #2 / 12 gallons (45.4L) Diesel #2 / 12 gallons (45.4L)

Toro Diesel Z Master Specifications

General

Fuel Type	Diesel
Transmission	Hydrostatic
Engine Type	Diesel
Cutting Width	60 inches
Fuel Tank Capacity	12 gallons
