SPECIFICATIONS
2-5Z580/Z593/Z595 Diesel Service Manual
2
Specifi cations Z580-D cont.
Z580-D
Type TURBO FORCE™
Deck Construction Fabricated, 7-ga Steel w/Bull-Nose bumper
Deck Material High-Strength Steel
Deck Depth 5-1/2” (13.97cm)
Adjustable Discharge Baffl e Standard
Spindle Housings 9-3/8” (23.8cm) Diameter Cast Iron
Spindle Shaft / Bearings 1” (2.54cm) Steel Shaft/Tapered Roller
Blades (3) 1/4” (.635cm) Heat Treated Steel
Blade Tip Speed 18,500 ft/min (5,638.8 meters/min)
Belt Construction Single Kevlar cord V-Belt
Cutting Height 1-1/2” - 5” in .25” increments
(3.81 - 12.7cm in .635cm increments)
Anti-Scalp Rollers - 52”
Anti-Scalp Rollers - 60” / 72”
5 Standard
6 Standard
Carrier Frame Construction 2” x 2” x 3/16” (5.08 x 5.08 x .48cm)
Z580-D
Steering Controls 1.5” (3.81cm) Diameter Grips, Adjustable, Dampened
Seat Non-suspension - vinyl
Seat Belt Retractable
Arm Rests Standard
Seat Suspension System Optional
Beverage Holder Standard
Folding ROPS Standard
Z Stand Optional
Deck Lift Assist Pedal Standard
Mowing Deck
Operator Zone

Toro Diesel Z Master Specifications

General

Fuel Type	Diesel
Transmission	Hydrostatic
Engine Type	Diesel
Cutting Width	60 inches
Fuel Tank Capacity	12 gallons
