CHASSIS
3-22 Z580/Z593/Z595 Diesel Service Manual
3
Hood Assembly Replacement
Hood Assembly Removal
Hood Assembly Installation
3. Lift the hood and remove it from the machine (Fig.
085).
Fig 083 IMG_7836
Fig 085 IMG_7848
1. Align the hood pivot brackets with holes in the pivot
bracket on the frame (Fig. 086).
2. Remove the two hairpins, clevis pins, and washers
located in the left and right hinges (Fig. 084).
Fig 086 IMG_7854a
Fig 084 IMG_7844
1. Unhook the rubber latch that is located on the rear of
the hood (Fig. 083).
