SPECIFICATIONS
2-4 Z580/Z593/Z595 Diesel Service Manual
2
Z580-D
Heavy Duty Canister Air Cleaner Standard
Clutch Adjustable .015” - .021” (0.35mm - 0.65mm)
Ogura 150 ft-lbs. (203.37 Nm)
Hydraulic Pump Tandem Hydro-Gear® variable displacement
16cc, w/shock valves
Hydraulic Oil System Capacity 4.2 quarts (4.0 liters)
Wheel Motors(2) Twin Hydro-Gear® 18E, positive displacement
1.25” (3.2cm) Tapered Shaft
Maximum Ground Speed (f/r) 11 mph / 6.3 mph (17.7km/hr / 10km/hr)
Hour Meter Standard
Rear Drive Tires 24 x 12.0 - 12 (52”)
23 x 9.5 - 12 (60” & 72”)
Front Caster Tires Semi-Pneumatic 13 x 6.50 - 6
Fuel / Capacity Diesel # 2 or 20% Bio-Diesel / 12 gallons
(45 liters)
Specifi cations Z580-D
Confi gurations
Power System
Z580-D
25 hp Kubota Liquid-Cooled Diesel 52”/60”/72” Turbo Force
