MOWER DECKS
7-30 Z580/Z593/Z595 Diesel Service Manual
7
15. Lower the fl oor pan assembly (Fig. 796).
1. Park the machine on a level surface, disengage the
PTO, turn the ignition off and remove the key.
2. Raise the seat.
3. Remove the negative battery cable from the battery.
4. Raise the fl oor pan assembly (Fig. 797).
Fig 796 PICT-4011
Fig 797 PICT-4011
16. Install the negative battery cable to the battery.
17. Lower the seat.
Fixed Pulley Replacement
Fixed Pulley Removal
