3-9Z580/Z593/Z595 Diesel Service Manual
3
Fuel Tank Replacement
Right Side Fuel Tank Removal
14. Install the axle bolt and nut securing the wheel as-
sembly to the fork (Fig. 032).
1. Raise the seat and remove the front engine shield
(Fig. 034).
Fig 032 IMG_7736
Fig 034 IMG_7751
2. Turn the fuel shut-off valve to the OFF position (Fig.
035).
15. Apply grease (No. 2 general purpose lithium base or
molybdenum grease) to the wheel assembly grease
fi tting (Fig. 033).
Fig 035 IMG_7896
Fig 033 IMG_7886
