ABOUT THIS MANUAL
This service manual was written expressly for Toro service technicians. The Toro Company has made every effort to
make the information in this manual complete and correct.
Basic shop safety knowledge and mechanical/electrical skills are assumed. The Table of Contents lists the systems
and the related topics covered in this manual.
The following service materials are available in addition to this service manual:
Hydrostatic Pumps: Hydro-Gear P Series Pumps - Service and Repair Manual
Form #BLN 52503
Wheel Motors: Hydro-Gear HGM-E Wheel Motor Service Manual
Form #492-9139
Diesel Engine: Kubota D722/D902 3 Cylinder Liquid-Cooled Engine Repair Manual
Form #492-4796
Hydraulic Troubleshooting: Interactive hydraulic troubleshooting and failure analysis on DVD
Form #492-4777
Electrical Troubleshooting: Interactive electrical troubleshooting and wiring diagrams on DVD
Form # 492-9171
The Z Master 593/595/580 model years 2006 to 2008 are covered in this manual. The manual may also be specifi ed
for use on later model products.
The hydrostatic drive system is precision machinery. Maintain strict cleanliness control during all stages of service
and repair. Cover or cap all hose ends and fi ttings whenever they are exposed. Even a small amount of dirt or other
contamination can severely damage the system.
We are hopeful that you will fi nd this manual a valuable addition to your service shop. If you have any questions or
comments regarding this manual, please contact us at the following address:
The Toro Company
LCE Service Training Department
8111 Lyndale Avenue South
Bloomington, MN 55420
The Toro Company reserves the right to change product specifi cations or this manual without notice.
Copyright© All Rights Reserved
©2008 The Toro Company
