132 Program features
Programmable digital inputs
The drive has five programmable digital inputs. The update time for the digital inputs
is 2 ms.
One digital input (DI5) can be programmed as a frequency input. See section
Frequency input on page 133.
Settings
Diagnostics
PAR AO SCALE Incorrect AO signal scaling (1503 < 1502)
Parameter Additional information
Group 10 START/STOP/DIR DI as start, stop, direction
Group 11 REFERENCE SELECT DI in reference selection, or reference source
Group 12 CONSTANT SPEEDS DI in constant speed selection
Group 16 SYSTEM CONTROLS DI as external Run enable, fault reset or user macro
change signal
Group 19 TIMER & COUNTER DI as timer or counter control signal source
2013, 2014 DI as torque limit source
2109 DI as external emergency stop command source
2201 DI as acceleration and deceleration ramp selection
signal
2209 DI as zero ramp force signal
3003 DI as external fault source
Group 35 MOTOR TEMP MEAS DI in motor temperature measurement
3601 DI as timed function enable signal source
3622 DI as booster activation signal source
4010/4110/4210 DI as PID controller reference signal source
4022/4122 DI as sleep function activation signal in PID1
4027 DI as PID1 parameter set 1/2 selection signal source
4228 DI as external PID2 function activation signal source
Group 84 SEQUENCE PROG DI as Sequence programming control signal source
Actual signal Additional information
0160 DI status
0414 DI status at the time the latest fault occurred
Actual signal Additional information
