Technical data 363
Dimensions, weights and free space requirements
 Dimensions and weights
 Free space requirements
Frame
size
Dimensions and weights
IP20 (cabinet) / UL open
H1 H2 H3 W D Weight
mm in mm in mm in mm in mm in kg lb
R0 169 6.65 202 7.95 239 9.41 70 2.76 161 6.34 1.2 2.6
R1 169 6.65 202 7.95 239 9.41 70 2.76 161 6.34 1.2 2.6
R2 169 6.65 202 7.95 239 9.41 105 4.13 165 6.50 1.7 3.7
R3 169 6.65 202 7.95 236 9.29 169 6.65 169 6.65 2.9 6.4
R4 181 7.13 202 7.95 244 9.61 260 10.24 169 6.65 5.1 11.2
00353783.xls J
Frame
size
Dimensions and weights
IP20 / NEMA 1
H4 H5 W D Weight
mm in mm in mm in mm in kg lb
R0 257 10.12 280 11.02 70 2.76 169 6.65 1.6 3.5
R1 257 10.12 280 11.02 70 2.76 169 6.65 1.6 3.5
R2 257 10.12 282 11.10 105 4.13 169 6.65 2.1 4.6
R3 260 10.24 299 11.77 169 6.65 177 6.97 3.5 7.7
R4 270 10.63 320 12.60 260 10.24 177 6.97 5.7 12.6
00353783.xls J
Symbols
IP20 (cabinet) / UL open
H1 height without fastenings and clamping plate
H2 height with fastenings, without clamping plate
H3 height with fastenings and clamping plate
IP20 / NEMA 1
H4 height with fastenings and connection box
H5 height with fastenings, connection box and hood
Frame
size
Free space required
Above Below On the sides
mm in mm in mm in
R0…R4753753 0 0
00353783.xls J

ABB ACS355 Specifications

General

Input Voltage	200 V to 240 V AC, 380 V to 480 V AC
Frequency	47 Hz to 63 Hz
Control Method	Scalar control
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Modbus RTU, CANopen
Enclosure Rating	IP20
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Storage Temperature	-40°C to +70°C (-40 to +158 °F)
Humidity	95% RH (non-condensing)
Altitude	Up to 1000 m (3280 ft) without derating
