356 Maintenance and hardware diagnostics
Control panel
Cleaning the control panel
Use a soft damp cloth to clean the control panel. Avoid harsh cleaners which could
scratch the display window.
Changing the battery in the assistant control panel
A battery is only used in assistant control panels that have the clock function
available and enabled. The battery keeps the clock operating in memory during
power interruptions.
The expected life for the battery is greater than ten years. To remove the battery, use
a coin to rotate the battery holder on the back of the control panel. Replace the
battery with type CR2032.
Note: The battery is NOT required for any control panel or drive functions, except the
clock.
LEDs
There is a green and a red LED on the front of the drive. They are visible through the
panel cover but invisible if a control panel is attached to the drive. The assistant
control panel has one LED. The table below describes the LED indications.
Where LED off LED lit and steady LED blinking
On the front of
the drive.
If a control panel
is attached to the
drive, switch to
remote control
(otherwise a fault
will be
generated), and
then remove the
panel to be able
to see the LEDs.
No power Green Power supply on
the board OK
Green Drive in an alarm
state
Red Drive in a fault
state. To reset
the fault, press
RESET from the
control panel or
switch off the
drive power.
Red Drive in a fault state.
To reset the fault,
switch off the drive
power.
At the top left
corner of the
assistant control
panel
Panel has no
power or no
drive
connection.
Green Drive in a normal
state
Green Drive in an alarm
state
Red Drive in a fault
state. To reset
the fault, press
RESET from the
control panel or
switch off the
drive power.
Red -
