ABB ACS355 User Manual

Technical data 365
 Noise
3-phase U
N
= 380…480 V (380, 400, 415, 440, 460, 480 V)
03x-01A2-4 11 6.6 24.4 - -
03x-01A9-4 16 6.6 24.4 - -
03x-02A4-4 21 9.8 28.7 13 8
03x-03A3-4 31 9.8 28.7 13 8
03x-04A1-4 40 9.8 28.7 13 8
03x-05A6-4 61 9.8 28.7 19 11
03x-07A3-4 74 14.1 32.7 24 14
03x-08A8-4 94 14.1 32.7 24 14
03x-12A5-4 130 12.0 31.2 52 31
03x-15A6-4 173 12.0 31.2 52 31
03x-23A1-4 266 16.6 35.4 71 42
03x-31A0-4 350 33.4 57.8 96 57
03x-38A0-4 440 33.4 57.8 96 57
03x-44A0-4 530 33.4 57.8 96 57
00353783.xls J
Frame
size
Noise level
dBA
R0 <30
R1 50…62
R2 50…62
R3 50…62
R4 <62
00353783.xls J
Type Heat dissipation Air flow
ACS355- Main circuit Control circuit
x = E/U Rated /
1N
and /
2N
Min Max
W W W m
3
/h ft
3
/min

ABB ACS355 Specifications

General

Input Voltage	200 V to 240 V AC, 380 V to 480 V AC
Frequency	47 Hz to 63 Hz
Control Method	Scalar control
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Modbus RTU, CANopen
Enclosure Rating	IP20
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Storage Temperature	-40°C to +70°C (-40 to +158 °F)
Humidity	95% RH (non-condensing)
Altitude	Up to 1000 m (3280 ft) without derating
