ABB ACS355 User Manual

280 Actual signals and parameters
5318 EFB PAR 18 For Modbus: Sets an additional delay before the drive
begins transmitting response to the master request.
0
0…65535 Delay in milliseconds 1 = 1
5319 EFB PAR 19 ABB drives profile (ABB DRV LIM or ABB DRV FULL)
Control word. Read only copy of the fieldbus Control word.
0000 hex
0000…FFFF
hex
Control word
5320 EFB PAR 20 ABB drives profile (ABB DRV LIM or ABB DRV FULL)
Status word. Read only copy of the fieldbus Status word.
0000 hex
0000…FFFF
hex
Status word
54 FBA DATA IN Data from the drive to the fieldbus controller through a
fieldbus adapter. See chapter Fieldbus control with fieldbus
adapter on page 325.
Note: In adapter module the parameter group number is 3.
5401 FBA DATA IN 1 Selects data to be transferred from the drive to the fieldbus
controller.
0 Not in use
1…6 Control and status data words
101…9999 Parameter index
5402 FBA DATA IN 2 See 5401 FBA DATA IN 1.
…… …
5410 FBA DATA IN
10
See 5401 FBA DATA IN 1.
55 FBA DATA OUT Data from the fieldbus controller to the drive through a
fieldbus adapter. See chapter Fieldbus control with fieldbus
adapter on page 325.
Note: In adapter module the parameter group number is 2.
5501 FBA DATA
OUT 1
Selects data to be transferred from the fieldbus controller to
the drive.
0 Not in use
All parameters
No. Name/Value Description Def/FbEq
5401 setting Data word
1 Control word
2REF1
3REF2
4Status word
5 Actual value 1
6 Actual value 2

ABB ACS355 Specifications

General

Input Voltage	200 V to 240 V AC, 380 V to 480 V AC
Frequency	47 Hz to 63 Hz
Control Method	Scalar control
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Modbus RTU, CANopen
Enclosure Rating	IP20
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Storage Temperature	-40°C to +70°C (-40 to +158 °F)
Humidity	95% RH (non-condensing)
Altitude	Up to 1000 m (3280 ft) without derating
