ABB ACS355 User Manual

Fault tracing 341
Alarms generated by the basic control panel
The basic control panel indicates control panel alarms with a code, A5xxx.
ALARM CODE CAUSE WHAT TO DO
5001 Drive is not responding. Check panel connection.
5002 Incompatible
communication profile
Contact your local ABB representative.
5010 Corrupted panel parameter
backup file
Retry parameter upload.
Retry parameter download.
5011 Drive is controlled from
another source.
Change drive control to local control mode.
5012 Direction of rotation is
locked.
Enable change of direction. See parameter
1003 DIRECTION.
5013 Panel control is disabled
because start inhibit is
active.
Start from panel is not possible. Reset
emergency stop command or remove 3-wire
stop command before starting from panel.
See section 3-wire macro on page 113 and
parameters 1001 EXT1 COMMANDS, 1002
EXT2 COMMANDS and 2109 EMERG STOP
SEL.
5014 Panel control is disabled
because of drive fault.
Reset drive fault and retry.
5015 Panel control is disabled
because local control
mode lock is active.
Deactivate local control mode lock and retry.
See parameter 1606 LOCAL LOCK.
5018 Parameter default value is
not found.
Contact your local ABB representative.
5019 Writing non-zero
parameter value is
prohibited.
Only parameter reset is allowed.
5020 Parameter or parameter
group does not exist or
parameter value is
inconsistent.
Contact your local ABB representative.
5021 Parameter or parameter
group is hidden.
Contact your local ABB representative.
5022 Parameter is write
protected.
Parameter value is read-only and cannot be
changed.
5023 Parameter change is not
allowed when drive is
running.
Stop drive and change parameter value.
5024 Drive is executing a task. Wait until task is completed.
5025 Software is being uploaded
or downloaded.
Wait until upload/download is complete.
5026 Value is at or below
minimum limit.
Contact your local ABB representative.
5027 Value is at or above
maximum limit.
Contact your local ABB representative.
5028 Invalid value Contact your local ABB representative.

ABB ACS355 Specifications

General

Input Voltage	200 V to 240 V AC, 380 V to 480 V AC
Frequency	47 Hz to 63 Hz
Control Method	Scalar control
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Modbus RTU, CANopen
Enclosure Rating	IP20
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Storage Temperature	-40°C to +70°C (-40 to +158 °F)
Humidity	95% RH (non-condensing)
Altitude	Up to 1000 m (3280 ft) without derating
