276 Actual signals and parameters
51 EXT COMM
MODULE
The parameters need to be adjusted only when a fieldbus
adapter module (optional) is installed and activated by
parameter 9802 COMM PROT SEL. For more details on the
parameters, refer to the manual of the fieldbus module and
chapter Fieldbus control with fieldbus adapter on page 325.
These parameter settings will remain the same even though
the macro is changed.
Note: In adapter module the parameter group number is 1.
5101 FBA TYPE Displays the type of the connected fieldbus adapter module.
NOT DEFINED Fieldbus module is not found, or it is not properly
connected, or parameter 9802 COMM PROT SEL setting is
not EXT FBA.
0
PROFIBUS-DP Profibus adapter module 1
CANopen CANopen adapter module 32
DEVICENET DeviceNet adapter module 37
5102 FB PAR 2 These parameters are adapter module-specific. For more
information, see the module manual. Note that not all of
these parameters are necessarily visible.
……
5126 FB PAR 26
5127 FBA PAR
REFRESH
Validates any changed adapter module configuration
parameter settings. After refreshing, the value reverts
automatically to DONE.
DONE Refreshing done 0
REFRESH Refreshing 1
5128 FILE CPI FW
REV
Displays the parameter table revision of the fieldbus adapter
module mapping file stored in the memory of the drive.
Format is xyz where:
• x = major revision number
• y = minor revision number
• x = correction letter.
0000…FFFF
hex
Parameter table revision 1 = 1
5129 FILE CONFIG
ID
Displays the drive type code of the fieldbus adapter module
mapping file stored in the memory of the drive.
0…65535 Drive type code of fieldbus adapter module mapping file 1 = 1
5130 FILE CONFIG
REV
Displays the fieldbus adapter module mapping file revision
stored in the memory of the drive in decimal format.
Example: 1 = revision 1.
0…65535 Mapping file revision 1 = 1
5131 FBA STATUS Displays the status of the fieldbus adapter module
communication.
IDLE Adapter is not configured. 0
EXECUT INIT Adapter is initializing. 1
All parameters
No. Name/Value Description Def/FbEq
