Appendix: Extension modules 393
Appendix: Extension
modules
What this chapter contains
The appendix describes common features and mechanical installation of the optional
extension modules for the ACS355: MPOW-01 auxiliary power module, MTAC-01
pulse encoder interface module and MREL-01 output relay module.
The appendix also describes specific features and electrical installation for the
MPOW-01; for information on the MTAC-01 and MREL-01, refer to the corresponding
user’s manual.
Extension modules
 Description
Extension modules have similar enclosures and they are mounted between the
control panel and the drive. Therefore only one extension module can be used for a
drive. ACS355 IP66/67 / UL Type 4X drives are not compatible with extension
modules due to space restrictions.
The following optional extension modules are available for the ACS355. The drive
automatically identifies the module, which is ready for use after the installation and
power-up.
• MTAC-01 pulse encoder interface module
• MREL-01 output relay module
• MPOW-01 auxiliary power module.

ABB ACS355 Specifications

General

Input Voltage	200 V to 240 V AC, 380 V to 480 V AC
Frequency	47 Hz to 63 Hz
Control Method	Scalar control
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Modbus RTU, CANopen
Enclosure Rating	IP20
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Storage Temperature	-40°C to +70°C (-40 to +158 °F)
Humidity	95% RH (non-condensing)
Altitude	Up to 1000 m (3280 ft) without derating
