272 Actual signals and parameters
4125 WAKE-UP DEV See parameter 4025 WAKE-UP DEV.
4126 WAKE-UP
DELAY
See parameter 4026 WAKE-UP DELAY.
42 EXT / TRIM PID External/Trim PID (PID2) control. See section PID control
on page 149.
4201 GAIN See parameter 4001 GAIN.
4202 INTEGRATION
TIME
See parameter 4002 INTEGRATION TIME.
4203 DERIVATION
TIME
See parameter 4003 DERIVATION TIME.
4204 PID DERIV
FILTER
See parameter 4004 PID DERIV FILTER.
4205 ERROR
VALUE INV
See parameter 4005 ERROR VALUE INV.
4206 UNITS See parameter 4006 UNITS.
4207 UNIT SCALE See parameter 4007 UNIT SCALE.
4208 0% VALUE See parameter 4008 0% VALUE.
4209 100% VALUE See parameter 4009 100% VALUE.
4210 SET POINT
SEL
See parameter 4010 SET POINT SEL.
4211 INTERNAL
SETPNT
See parameter 4011 INTERNAL SETPNT.
4212 SETPOINT
MIN
See parameter 4012 SETPOINT MIN.
4213 SETPOINT
MAX
See parameter 4013 SETPOINT MAX.
4214 FBK SEL See parameter 4014 FBK SEL.
4215 FBK
MULTIPLIER
See parameter 4015 FBK MULTIPLIER.
4216 ACT1 INPUT See parameter 4016 ACT1 INPUT.
4217 ACT2 INPUT See parameter 4017 ACT2 INPUT.
4218 ACT1
MINIMUM
See parameter 4018 ACT1 MINIMUM.
4219 ACT1
MAXIMUM
See parameter 4019 ACT1 MAXIMUM.
4220 ACT2
MINIMUM
See parameter 4020 ACT2 MINIMUM.
4221 ACT2
MAXIMUM
See parameter 4021 ACT2 MAXIMUM.
4228 ACTIVATE Selects the source for the external PID function activation
signal. Parameter 4230 TRIM MODE must be set to NOT
SEL.
NOT SEL
NOT SEL No external PID control activation selected 0
DI1 Digital input DI1. 1 = active, 0 = inactive. 1
DI2 See selection DI1.2
All parameters
No. Name/Value Description Def/FbEq
