Program features 165
 Settings
Timer
Drive start and stop can be controlled with timer functions.
 Settings
 Diagnostics
Counter
Drive start and stop can be controlled with counter functions. The counter function
can also be used as state change trigger signal in Sequence programming. See
section Sequence programming on page 166.
 Settings
Parameter Additional information
36 TIMED FUNCTIONS Timed functions settings
1001, 1002 Timed start/stop control
1102 Timed EXT1/EXT2 selection
1201 Timed constant speed 1 activation
1209 Timed speed selection
1401 Timed function status indicated through relay output RO 1
1402/1403/1410 Timed function status indicated through relay output RO 2…4.
With option MREL-01 only.
1805 Timed function status indicated through digital output DO
4027 Timed PID1 parameter set 1/2 selection
4228 Timed external PID2 activation
8402 Timed Sequence programming activation
8425/8435/…/8495
8426/8436/…/8496
Sequence programming state change trigger with timed
function
Parameter Additional information
1001, 1002 Start/stop signal sources
Group 19 TIMER & COUNTER Timer for start and stop
Actual signal Additional information
0165 Start/stop control time count
Parameter Additional information
1001, 1002 Start/Stop signal sources
Group 19 TIMER & COUNTER Timer for start and stop
8425, 8426 / 8435, 8436 /…/8495,
8496
Counter signal as state change trigger in Sequence
programming

ABB ACS355 Specifications

General

Input Voltage	200 V to 240 V AC, 380 V to 480 V AC
Frequency	47 Hz to 63 Hz
Control Method	Scalar control
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Modbus RTU, CANopen
Enclosure Rating	IP20
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Storage Temperature	-40°C to +70°C (-40 to +158 °F)
Humidity	95% RH (non-condensing)
Altitude	Up to 1000 m (3280 ft) without derating
